Seawater Desalination Equipment For Container 500m3/d Capacity

Product Description:

The total installed power of the equipment is about 161.5kW, the operating power is about 90kW, and the electricity consumption per ton is about 4.32kWh


The 500m3/d seawater desalination unit is in the form of a container, requiring a 40-foot high container and
Each 40-foot standard container has 1 set, and the length, width and height of the 40-foot high container are about 12m×2.3m×2.7m.


The length, width and height of a 40-foot standard container are 12m x 2.3m x 2.4m.


Air flotation device, quartz sand filter and water tank, located outside the container


The process flow is as follows: original water tank – raw water booster pump – air float – sand filter inlet pump – two-stage quartz sand filtration – sand filter production tank – reverse osmosis inlet pump – security filter – high pressure pump – energy recovery device – reverse osmosis – production tank. Seawater is taken out by the pump, first into the original water tank to adjust the water quality and quantity, and then transported to the air floating tank by the raw water booster pump to remove most of the suspended solids, colloids, algae, etc., and then transported to the two-stage quartz sand filter by the sand filter supply pump to remove most of the suspended solids, sediment, colloids, particles and other impurities in the seawater, and the filtered water enters the sand filter production tank. After the pre-treated water passes through the security filter, it is pressurized by high pressure pump into the reverse osmosis desalting system. The reverse osmosis system carries the pressurized concentrated water into the energy recovery device for pressure recovery, and the low-pressure concentrated water is discharged. After disinfection and tempering, the produced water is transported to the water point through the water supply system.

Company Information:

Henan Yanjiang Environmental Technology Co., Ltd. as a professional integrated environmental service provider, Committed to the continuous improvement of traditional business and the development of forward-looking business, for the global cities, towns and enterprises, to provide environmental and development of the overall solution and long-term stewardship service, in the field of environmental pollution control and facility operation, sewage treatment, seawater desalination, water purification equipment and water reuse, organic waste comprehensive utilization and biomass energy development and utilization, the environment Business activities are carried out in the fields of restoration, environmental safety management, environmental advisory services and environmental investment and financing management.

FAQ:

Q: What is the brand name of the Seawater Desalination Equipment?
A: The brand name is Yanjiang.
Q: Where is the Seawater Desalination Equipment manufactured?
A: The equipment is manufactured in Yanjiang.
Q: Is the Seawater Desalination Equipment certified?
A: Yes, the equipment is certified by Yanjiang.
Q: What is the minimum order quantity for the Seawater Desalination Equipment?
A: The minimum order quantity needs to be negotiated.
Q: What are the accepted payment terms for purchasing the Seawater Desalination Equipment?
A: The accepted payment terms are L/C, D/A, D/P, T/T, Western Union, and MoneyGram.
