6m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System

  • 6m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System
  • 6m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System
  • 6m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System
  • 6m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System
Place of Origin China
Brand Name Yanjiang
Certification CE、ISO
Model Number 10
Minimum Order Quantity Need to negotiate
Price Need to negotiate
Delivery Time 15-20work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 20 Sets Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Weight 17kgs Size 600*40*760mm
Produced Water Turbidity <0.3 NTU SS=0 SDI<4 Effective Membrane Area 6m²
Produced Water Qty.(L/day) 1440~5760 Pore Size 0.034um/0.2um
Material Reinforced PVDF (PVDF With PET Tube) TMP 0.02-0.05Mpa
Highlight

mbr membrane integrated

,

6m2 mbr module

,

6m2 mbr membrane
Leave a Message
Product Description

Manufacturer 6m2 mbr wastewater treatment mbr membrane integrated sewage services mbr module system



Product description:

Discover our state-of-the-art Sewage Treatment MBR (Membrane Bio-Reactor) System, an integrated solution designed for efficient and sustainable wastewater management. Our MBR system is a compact and comprehensive unit that combines biological degradation with ultra-filtration membrane technology, providing a high-quality effluent suitable for various reuse applications.

Key Features:

  • High-Performance Membranes: Our MBR system utilizes advanced membrane technology that ensures effective separation of solids from the liquid, resulting in superior water quality.
  • Modular Design: The system is built with a modular approach, allowing for scalability and easy integration into existing infrastructure.
  • Minimal Sludge Production: The MBR process significantly reduces the amount of sludge generated, lowering disposal costs and environmental impact.
  • Low Operational Cost: With automated operation and minimal maintenance requirements, our system is designed to be cost-effective in the long term.
  • Environmentally Friendly: The treated water meets stringent environmental standards, making it ideal for reuse in landscaping, irrigation, and other non-potable uses.

Our MBR system is not just a sewage treatment solution; it's a step towards a cleaner and more sustainable future. Invest in our technology for a reliable and eco-friendly wastewater treatment service.



Membrane material Poly vinylidene fluoride(PVDF with Reinforced lining)
Membrane Pore size 0.034-0.1µm
Membrane fiber (ID/OD) 1.0/2.2mm, 0.8/1.9mm,1.0/2.0mm
Filter method Negative pressure suction mode
TPM(Max) 50Kpa
Designed Flux 10-40L/㎡·h
PH Range 2-11
Temperature Range 5-40℃
MLSS Range 4000-12000mg/L (min:3000mg/L, max:15000mg/L)

6m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System 06m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System 16m2 Water Treatment Mbr Membrane Integrated Sewage Services Mbr Module System 2



Company Information:

Henan Yanjiang Environmental Technology Co., Ltd. as a professional integrated environmental service provider, Committed to the continuous improvement of traditional business and the development of forward-looking business, for the global cities, towns and enterprises, to provide environmental and development of the overall solution and long-term stewardship service, in the field of environmental pollution control and facility operation, sewage treatment, seawater desalination, water purification equipment and water reuse, organic waste comprehensive utilization and biomass energy development and utilization, the environment Business activities are carried out in the fields of restoration, environmental safety management, environmental advisory services and environmental investment and financing management.



FAQ:

Q1:Are you trading company or manufacturer?
A:We are factory.
Q2:How long is your delivery time?
A:Generally it is 15~20 days. Specific time depends on your ordel volume.
Q3:Can l get your products with our logo and design?A:Customized service is available. We provide OEM or ODM by customer's logo
Q4: Do you accept sample order?
A: Yes,we can make your customized sample before mass order placed.
Q5: How about the quality of your products?
A:We have many years of experience in construction machinery manufacturing. All machines are
Manufactured in strict accordance with national and international standards, each equipment is tested before leaving the factory.
